RK3399 Android Media Player Box Multi-Language Support Wifi BT RJ45 USB HDMI

Certificación
CHINA Shenzhen Sunchip Technology Co., Ltd. certificaciones
CHINA Shenzhen Sunchip Technology Co., Ltd. certificaciones
Comentarios de cliente
¡Noticias impresionantes! Sé que su equipo ha trabajado difícilmente, las gracias por final el proyecto tan rápidamente.

—— Caminante de Brian

Me gusta su muestra mucho. El en espera crecer nuestra sociedad

—— Jenny Westbrook

Estoy en línea para chatear ahora

RK3399 Android Media Player Box Multi-Language Support Wifi BT RJ45 USB HDMI

RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI
RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI
RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI

Ampliación de imagen :  RK3399 Android Media Player Box Multi-Language Support Wifi BT RJ45 USB HDMI

Datos del producto:
Place of Origin: China
Nombre de la marca: SUNCHIP
Número de modelo: Cuadro AD-0150 (AD-B03)
Pago y Envío Términos:
Cantidad de orden mínima: 1 pieza
Precio: $80-$112/piece
Detalles de empaquetado: 1 pieza por caja, 5 piezas en una caja de cartón
Delivery Time: 1~3 days if have stock, 15-25 days if no stock
Payment Terms: T/T, Western Union, PayPal, L/C
Supply Ability: 1000 pieces per month

RK3399 Android Media Player Box Multi-Language Support Wifi BT RJ45 USB HDMI

descripción
Conexión Ethernet: 10/100/1000M Lan Expansion: TF Card Slot
Serial Port: 3*Serial Port (UART) Language Support: Multi-language
Interfaces: USB/HD/RJ45/SIM/TF slot Rom: 16GB, 32GB, 64GB optional
Internet: WIFI,BT,WLAN,3G,4G Resolución máxima: 4K
Usb: USB2.0*3, USB3.0*1 Temperatura de trabajo: -10°C~50°C
RAM: 4G Procesador: RK3399 Hexa Core para Android 10
Resaltar:

RK3399 Caja de reproductor de medios Android

,

Caja del reproductor de medios de Android Wifi

,

Caja de reproductor de medios para Android

Product Description:



Android Media Player Box, used for digital signage display.



The SUNCHIP Android Digital Signage Displays Box Media Player Box is a cutting-edge device designed to revolutionize the way businesses communicate with their audience.



This powerful media player box combines advanced technology with sleek design, making it the perfect solution for any digital signage needs.



RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI 0



It supports 4K high-definition display and comes with built-in Signag digital display software



With its 4K HD resolution, this Android box delivers stunning visuals that bring your content to life.



Whether you're displaying advertisements, information, or promotional videos, the crystal-clear display ensures that every detail is portrayed with utmost clarity and sharpness.



RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI 1





Connected to monitor and play advertisements, videos, images, and other content through the internet or USB





Equipped with built-in signage software, this digital signage displays box eliminates the need for additional hardware or software installations.



It seamlessly integrates with various digital signage platforms, making content management and scheduling effortless.



With just a few clicks, you can update and manage your content remotely, ensuring that your message reaches your audience in real-time.



RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI 2



Suitable for commercial venues, exhibitions, hotels, restaurants, and other occasions where information needs to be displayed.



The SUNCHIP Android Digital Signage Displays Box Media Player Box provides a seamless user experience with its intuitive interface.



Effortlessly navigate through menus and settings, customize layouts, and schedule playlists with ease.



Its user-friendly design makes it accessible for users of all levels of technical expertise.



RK3399 Android Media Player Box  Multi-Language Support  Wifi  BT RJ45 USB HDMI 3



Technical Parameters::



System CPU Quad-core 64 bits Cortex-A55,main frequency up to 2.0GHz
GPU ARM G52 2EE, supporting OpenGL ES 1.1/2.0/3.2,OpenCL 2.0,Vulkan 1.1, Embedded with high performance 2D acceleration hardware
NPU Support 1T computing power
RAM 2GB/4GB (optional)
ROM 8GB/16GB/32GB/64GB (optional)
OS Android 10
Network WiFi IEEE 802.11b/g/n (Optional)
Ethernet Support 10/100/1000M Ethernet
Mobile Network Support 4G lte netowkr (Optional)
Bluetooth Bluetooth 5.2



Interfaces Upper Layer Interfaces RS232 RS232 Male DB9*1
USB 2.0 USB 2.0_A *2
HDMI_OUT_2 HDMI-A display port and support 1920*1080 60HZ output
Lower Layer Interfaces DC*1 DC_12V input and 5.5*2.1mm plug
Earphone 3.5mm and support Stereo headphone output
USB_OTG USB_A *1
USB 3.0 USB 3.0_A *1
HDMI_OUT_1 HDMI-A 2.0 display output(Support 3840*2160 60HZ output)
SIM Card Slot SIM Card Slot *1(Optional)
Extended Memory port TF Card Slot *1
Button Button Upgrade Button *1





Environmental Conditions Working environment Temperature: -20 ~ 60℃, 5%-85%RH (non-condensing)
Storage environment Temperature: -20 ~ 70℃, 5%-95%RH (non-condensing)
Material Shell Material Metal
Size Product Size Shell Size 190.6*98.9*34.7mm





Support and Services:



Media Player Technical Support and Services

We provide the following support and services for our Media Player product:

  • 24/7 customer service via phone and email
  • Online chat support
  • Datasheet
  • Software updates and security patches
  • Troubleshooting assistance
  • Hardware compatibility



FAQ:



Q1: How did I trust your company?
A: SUNCHIP a software and hardware solution provider who has 12-years old from Shenzhen, China. We have a good reputation in this industrial area when you check it with almost all of Shenzhen industrial suppliers.
Q2: How long will you ship out the goods after I place the order on you?
A: If in-stock, usually, it’ll take 1-3 days to prepare and ship out. Before shipping, we should do aging testing and normal function testing, QC inspection, then, ship out. If out of stock and need to re-produce the goods, it will take different lead time.

For android board, android media player box, android LCD digital signage machine, will take about 15-30 days, depending the product quantities and types.
Q3: After i get the products what if my products broken, what kind of service you support?
A: First contact us, tell us about the problem, our engineer will help to handle; secondly, you can send back the products to us, we will fix it. we support 12 months warranty, any problem catches me online, we can give you good solution way. we want to do long term business with you not just for 1 day 1 time.
Q4. Shipping solution?

We support Express, such as, DHL/FedEx/UPS/TNT etc., also support sea shipping, air shipping and railway shipping, depends on the customer’s request.
